Operational |
|
|
|
Video Standard |
NTSC / PAL |
|
|
Image Sensor |
4.1 Megapixel CMOS |
|
|
Effective Pixels |
2688(H)×1520(V) |
|
|
Illumination |
0 LUX, operates in total darkness |
|
|
Video Output |
CVI BNC, CVBS terminal |
|
|
Lens Mount |
Fixed |
|
|
Lens |
6mm Fixed (3.6, 6, 8 & 12mm
Optional) |
|
|
Sync System |
12 VDC: Internal |
|
|
S/N Ratio |
More than 52 dB (AGC off) |
|
|
Electronic Shutter |
PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
|
|
Gain Control |
Automatic |
|
|
White Balance |
Automatic |
|
|
BLC |
Automatic |
|
|
IR LED |
Smart IR LEDs |
|
|
IR Distance |
30 Meter |
|
|
DNR |
Automatic |
|
|
WDR |
Digital / Automatic |
|
|
Electrical |
|
|
|
Input Voltage |
12V DC |
|
|
Input Range |
±25% |
|
|
Surge Suppression |
1.5 KW transient |
|
|
Power Consumption |
DC12V±1V(Max 4W, Max 7W when IR cut switch) |
|
|
Mechanical |
|
|
|
Dimensions |
Φ70mm×165mm |
|
|
Weight |
550 grams |
|
|
Construction |
Brushed and anodized aluminum with sunshield |
|
|
Connector |
Video Output: BNC Connector Power Input: Tinned Leads |
|
|
Environmental |
|
|
|
Temperature |
-10oC ~ +55oC |
|
|
Relative Humidity |
0% to 85%, non-condensing |
|
|
Rating |
IP66 |
|
|
Regulatory |
||
|
Emissions |
FCC: Part 15, Class B CE: EN 55013 |
|
|
Immunity |
CE: EN50130-4 |
|
|
Safety |
EU: 73/23/EEC LVD |
|
