Rugged Keyboard K-TEK-M344KP-FN-BL-BT-ML-EMC-DWP

Mechanical Data

Keys

100 keys, durable and robust ploymer keys

Key top style

Protubent retangulat keys with tactile feeling

Key Size

14.0mm x 14.0mm for normal keys, 14.0mm x 28.0mm for enter key and 14.0mm x 68.2mm for space bar

Key travel

1.20+0.10mm

Actuation Force

2.0mm+0.2mm for key 14.0mm x 14.0mm (pressure point), 3.5N+0.2N for key 14.0mm x 28.9mm (Presure Point)

Front and Back Plate

Super quality SUS304 brushed stainless steel

Switch Life

more than 5 million of operations

GW

2.0KGs

Electrical Data

Supply Voltage

DC +5V+5%

Current rating

30mAwhen backlight is off, 300mA with backlight on

Note

Meet MIL-STD-461G with EMC (Electro Magnetic Compatibility) etc:

1

CE 101 25 kHz - 10MHz Conducted Emissions, Audio Frequency Currents, Power leads

2

CE 102 10 kHz - 10MHz Conducted Emissions, Radio Frequencu Potentials, Power leads

3

CS 101 25Hz - 250 kHz Conducted Emissions, Power leads

4

CS106 Conducted Susceptibility, Transients, Power Leads

5

CS112 Electrostatic Dsicharge susceptibility

6

CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection

7

CS115 Conducted Susceptbility, Bulk Cable injection, Impulse Excitation

8

CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads

9

RE101 25kHz Radiated Emissions, Magnetic Field

10

RE102 10kHz Radiated Emissions, Electroc Field

11

RS101 25kHz - 100kHz Radiated Susceptibility, Magnetic Field

12

RS103 10kHz - 40kHz Radiated Susceptibility, Electric Field

MIL-STD-810F (wide tempreture, shock, vibration, humidity)

Lifespan

> 5 years

Switch Contact Material

Military PCB withcarbon-on-gold key switch technology

Interface

USB or aviation plug available

Cable length

Standard 2.0m or 1.5M , customised length available

OS

All Windows, Linis, Unix, Mac OSX, Vxworks, Android, (U-cos--to be confirmed)

Environmental Adaptability

Operating tempreture

40C to 75C

Storage tempreture

45C to 85C

Humidity

100%

Atmospheric Presure

60-106Kpa

Saline mist

96 hours, IEC 60512-6

Damp heat test at +40C

21 days, IEC 60512-6

Dry heat test at +85C

10 days, IEC 60512-6

Reliability

Note

RoHS compliant, CE andFCC certified, MIL -STD-461G (EMC, EMI, EMS, ESD) and MIL -STD-810F (wide tempreture, shock, salt msit, vibration, fungus, humidity)

Protection level

IP65 dynamic (front panel)

Key Lifespan

>5 million actuations

MTBF

>20000H

MTTR

<30 min

APPLICANTION

Vehicle, aerospace, naval, defense, maritime, radar, console, portable, rugged laptop, UAV ground station etc
