HRUI 4 Port 100M POE Switch With 2*100M Ethernet Uplink

• HR500-AF-42 (4*10/100M POE ports +2*10/100M Uplink Ethernet port)

General parameter

Product name

6 ports 10M/100M Industrial intelligence standard POE Switch

Connector Type

4*10/100M POE ports +2* 10/100M Uplink Ethernet port

Network Protocols

IEEE802.3IEEE802.3uIEEE802.3x

POE Parameters

POE Standard: IEEE802.3at (30W) IEEE802.3af (15.4w)

Each port Max：

15.4 W (IEEE 802.3af)

Each port Max：

30 W (IEEE 802.3at)

POE compatibility：

IEEE 802.3af/at adaptive

POE port output：

DC 52V

POE power supply

core：1/2+ ; 3/6-

Network Media

10BASE-T: Cat3,4,5 UTP(≤100 m)10BASE-T：Cat6 or more UTP(≤250 m)100BASE-TX: Cat5 or more UTP(≤100 m)

Power Supply

Power input: DC48～55V)power supply wiring: 4 PIN (V1+V1-,V2+V2-）

Working Environment

Operating Temperature: -40～85℃Storage Temperature: -40～85℃Humidity: 5%~95 %( non-condensing)

Industry Standard

EMI: FCC Part 15, CISPR (EN55032) class AEMS: EN61000-4-2 (ESD)EN61000-4-4 (EFT)EN61000-4-5 (Surge)Shock: IEC 60068-2-27Free fall: IEC 60068-2-32Vibration: IEC 60068-2-6

Mechanical Structure

Shell protect grade: IP40Installation: DIN railN.W：0.409KG G.W: 0.489KG（without power supply）Product Dimension (L×W×H): 119MM*87MM*28MMPackage Dimension(L×W×H): 175MM*130MM*55MM

Certification

CE mark, commercialFCC Part 15 Class B

Package Contents

1.Industrial Switch： 1 unit2.User Guide：1unit3.Certificate warranty card：1unit

MTBF

100,000 hours

Warranty

5 years

Hardware parameter

Bandwidth

1.6Gbps

Cache

512K

Chipset

RTL8309NI

Package Forwarding Rate

0.8928Mpps

MAC address

2K

Forwarding mode

Store-and-forward
