Winmate 12.1" R12L600-MRM2HB Marine bridge system Display

12.1" Marine Bridge System Display Model: R12L600-MRM2HB -Dimming knob control backlight brightness from nearly 0% to 100% -High brightness TFT-LCD panel enhance the best visibility -Panel (flush) mount IP66 aluminum housing with powder coating design (IP54 rear) -9 to 36V DC power input acceptable -High quality touchscreen / AR protection glass for option -Ease of use front panel OSD control -Enhanced shock and vibration resistance

TFT Characteristics

Size

12.1"

Resolution

1024x768

Pixel Pitch (RGB)

0.240 (H) x 0.240 (V)

Contrast Ratio

1000 : 1 (typ.)

Panel Brightness

1000(typ.)

Viewing Angle

-89~89 (H); -89~89 (V)

Active Display Area

246.8 (H) x 185.4(V) mm

Max Colors

16.7M (8bits/color)

Input Signals

RGB Signal

D-SUB 15P connector(female)

Composite Video

RCA phono plug

S-Video Signal

S-Video (SVHS) plug

DVI-D Signal

DVI-D input 24pin connector

DC Power Signal

Screw terminal block

AC Power Signal (Optional)

Std IEC Inlet

Touch Screen

D-SUB 9P connector (female)

Remote control via RS-232

D-SUB 9P connector (female)

User Controls

Power Control

Power On/Off via Front Button

VR Control

VR Brightness Knob Control

Display Control

On Screen Display control(OSD)

OSD Remote Control

OSD Remote Control via RS-232

LED indicators

Power Mode Status LED

Power Considerations

Power Supply Options

9 to 36 V DC power supply with terminal block.

Power Consumption

54 W typical, normal operation

Mechanical Specification

Net Weight (kg) (with touch)

4.8

Operating Temperature

-10 to 55 deg.C (-20 to 60 deg.C for optional heating)

Operating Humidity

  • - SKU: 12.1" R12L600-MRM2HB Marine bridge system Display
  • - Brand: Winmate
Categories :

TFT Characteristics

Size

12.1"

Resolution

1024x768

Pixel Pitch (RGB)

0.240 (H) x 0.240 (V)

Contrast Ratio

1000 : 1 (typ.)

Panel Brightness

1000(typ.)

Viewing Angle

-89~89 (H); -89~89 (V)

Active Display Area

246.8 (H) x 185.4(V) mm

Max Colors

16.7M (8bits/color)

Input Signals

RGB Signal

D-SUB 15P connector(female)

Composite Video

RCA phono plug

S-Video Signal

S-Video (SVHS) plug

DVI-D Signal

DVI-D input 24pin connector

DC Power Signal

Screw terminal block

AC Power Signal (Optional)

Std IEC Inlet

Touch Screen

D-SUB 9P connector (female)

Remote control via RS-232

D-SUB 9P connector (female)

User Controls

Power Control

Power On/Off via Front Button

VR Control

VR Brightness Knob Control

Display Control

On Screen Display control(OSD)

OSD Remote Control

OSD Remote Control via RS-232

LED indicators

Power Mode Status LED

Power Considerations

Power Supply Options

9 to 36 V DC power supply with terminal block.

Power Consumption

54 W typical, normal operation

Mechanical Specification

Net Weight (kg) (with touch)

4.8

Operating Temperature

-10 to 55 deg.C (-20 to 60 deg.C for optional heating)

Operating Humidity
