Technical Description |
|
|
Model Name |
S17L500-OFM1 |
|
Panel Size |
17" |
|
Active Display Area (mm) |
337.92(H)x270.336(V) |
|
Resolution |
1280x1024 |
|
Panel Brightness |
350 (Typical) |
|
Contrast Ratio |
1000:1 (Typical) |
|
Viewing Angle |
-85~85 (H); -80~80 (V) |
|
Number of Colors |
16.2M (6 bits/color) |
|
Optional Touch Screen |
Optional 1: Resistive Touch, Protective Glass |
|
|
Optional 2: SAW Touch (Surface Acoustic Wave) |
|
Touch / Glass |
Resistive Touch Screen (Optional)
Protection Glass w/o Touch Function (Optional)
SAW Touch (Surface Acoustic Wave) (Optional |
|
Touch interface |
USB / RS232 |
|
Power Information |
|
|
Power Source |
12V DC in, with External AC-DC
Adapter(100~240V) |
|
Power Consumption |
27W typical, normal operation |
|
Display Signals |
|
|
Video Input |
Standard: 1 x VGA (D-sub 15), 1 x HDMI
(Type-A) |
|
OSD User Control |
5 Keys: - , + , Power , Esc , Enter |
|
Audio |
|
|
Audio |
Optional Audio line in (3.5mm) + Speaker x 2 |
|
Environment & Certification |
|
|
Operating Temperature (°C) |
0~50℃ |
|
Operating Humidity |
10% to 90% (noncondensing) |
|
Storage Temperature (°C) |
-10~60 ℃ |
|
Packing List |
|
|
Accessories |
Power AC-DC Adapter(100V~240V), VGA cable
(1.8m), HDMI cable (2m) |
| |
